G20 eight-axis embracing folding 22L agricultural spraying drone quick release double water tank battery
Packing list:
Frame kit 1: 12S integrated pump 2 + extension rod double nozzle 2 + Frame + landing gear + water tanks 2 + RTK fixings + AS150U power plug + camera fixing plate + screw accessory package
Frame kit 2: 12S integrated pump 4 + extension rod double nozzle 4 + Frame + landing gear + water tanks 2 + RTK fixings + AS150U power plug + camera fixing plate + screw accessory package
Frame parameters:
Wheelbase: 2122mm
Expanded size: 2050*2050*643mm
Folding size: 1107*1107*643mm
Medicine box capacity: 11L*2
Frame weight: 14kg (excluding spray system)
Recommended configuration:
Motor: hobbywing X8 / 8118
Paddle: 28-32 inch folding pulp
ESC: 80A FOC
Supply voltage: 12S
Maximum takeoff weight: 55kg
